[FEATURES]
- High performance VHF device, capable of voice communication and DSC (digital selective calling) facilities as well.
- Meet the regulations of ITU Regulation Appendix 18, ITU-R M.493-16, ITU-R M.541-11, IMO MSC.1/Circ.1460/Rev.5, IEC 61097-7, IEC 61097-3.
- 4-digit channels available.
- Dual watch function.
- Built-in GNSS receiver.
- ATIS function available.
- Marine communication handset.
- DSC class D.
- CCS type approval.
[SPECIFICATIONS]
TX Frequency: | 156.025 ~ 157.425 MHz |
RX Frequency: | 156.050 ~ 163.275 MHz |
Working Channel: | INT/USA/CAN/IWW/WX/PCH channels |
DSC Watch CH: | CH70 |
TX Power: | 25 W (high) / 1 W (low) |
| Class of Emission： | G3E（FM），G2B（DSC） |
RX Sensitivity: | ≤2μV (SINAD=20 dB) |
Interface: | |
| - GNSS Input: | RS422，4800bps |
- NMEA Output: | RS422，4800 (default)/9600/19200/ 38400/57600/115200 bps |
Power Supply: | DC 13.5V (range 12V ~15V), max 5.5 A |
Size: | 128.3 (H) × 263 (W) × 84 (D) mm |
Weight: | 1.05 kg (Transceiver) |
Operating Temperature: | -15° ~ 55°C (Transceiver, Handset) -40° ~ 55°C (Antenna) |
IP Grade: | IP22: Transceiver, Handset IP66: Antenna |
NSR NVR-2040 VHF RADIO BROCHURE.pdf
